Wearable Lifesaver: The Fall Detection Jacket

The Smart Jacket for Fall Detection is a life-saving application of Human Activity Recognition (HAR). It is designed for elderly care or extreme sports, using gravitational math to detect the sudden impact of a dangerous fall.


Acceleration Math

An MPU6050 (Accelerometer + Gyroscope) is sewn into the jacket.

  1. Normal Walking: The sensor measures standard 1G (gravity) pulling straight down toward the earth.
  2. The Fall: During a fall, the accelerometer registers chaotic spikes (e.g., hitting the floor can register a sudden spike of 3G or 4G).
  3. The Orientation Change: Crucially, after the impact spike, the gyroscope detects that the person is now lying horizontally (Pitch/Roll is ~90 degrees) instead of standing vertically.
  4. The Algorithm: if (impact > 3G && orientation_is_flat_for_10_seconds), the Arduino triggers the alarm.

The Hardware Implementation

  • Arduino Nano 33 BLE or ESP32: Small, lightweight, and internet-enabled.
  • MPU6050 6-Axis IMU.
  • GSM Module (SIM800L) or Wi-Fi: To send an SMS text message or push notification to the caregiver.
  • Piezo Buzzer: An audible alarm to alert people nearby.

This project introduces you to the concept of Wearables, shifting your focus from rigid plastic boxes to flexible wiring and battery management.
